Let’s learn about KTR Gear Couplings Bowex SG with Dai Hong Phat, through the following article!
1. About Dai Hong Phat Corp- KTR Germany
– Dai Hong Phat Corp is the official authorized representative of KTR Germany in Vietnam (KTR Vietnam). We provide genuine transmission shaft coupling solutions, meeting international standards, helping to optimize the performance and durability of machinery systems.
– KTR was established in 1959 in Germany. KTR is an abbreviation of
K – Kupplung (Coupling) | T – Technology (Technology) | R – Rheine (Region)
– KTR products: Rotex shaft coupling, Clampex shaft locking joint, hydraulic brake, …
– KTR Curved-Tooth Gear Couplings BoWex SG products supplied by Dai Hong Phat are 100% genuine imported, with full CO/CQ, meeting international quality standards.
Certificate of Dai Hong Phat as Authorized Distributor of KTR Germany in Vietnam
View more: Other KTR Gear Couplings
2. Characteristics of KTR Gear Couplings Bowex SG
– Manufacturer brand: KTR Germany.
– Includes a polyamide auxiliary ring, along with an O-ring to prevent dust intrusion into the shaft of the coupling.
– Polyamide material allows for permanent operation without maintenance with a very good tooth friction coefficient.
– According to the dual-action principle of the plastic-coated steel tooth coupling, the restoring force can displace angularly and radially without cyclic speed oscillations.
– KTR Bowex SG can be assembled either vertically or horizontally as per design.
– The smooth and hard surface (crystalline structure), along with high thermal stability and resistance to lubricants, fuels, hydraulic fluids, solvents, etc., makes Polyamide an ideal material for load-bearing sliding components, especially for coupling manufacturing.
View more product: Bowex AS Curved-Tooth Gear Couplings
| FOR ANY INQUIRIES OR QUOTATION REQUESTS, PLEASE CONTACT: SALES DEPARTMENT HOTLINE: +84 906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN |
3. Applications of the KTR Gear Couplings Bowex SG
The KTR Bowex SG curved-tooth gear coupling are versatile components used across various industries for reliable power transmission. They find application in pumps, compressors, mixers, conveyors, crushers, marine propulsion systems, wind turbines, and more. With their ability to withstand harsh conditions and transmit high torques, they offer efficient and dependable performance in diverse industrial settings.
4. Technical specifications of the KTR Bowex SG Curved-Tooth Gear Couplings
| Catalogue KTR Bowex SG |
Installation KTR Bowex SG |
||||||
 |
|
| Size | Finish bore | Dimensions [mm] | ||||||||
| Min. | Max. | l1, l2 | E | L | LH | M, N | D | DH | Hub length. max. l1, l2 |
|
| 24 SG | 10 | 24 | 36 | 4 | 76 | 51 | 12.5 | 36 | 58 | 50 |
| 28 SG | 10 | 28 | 40 | 4 | 84 | 56 | 14 | 44 | 70 | 55 |
| 32 SG | 12 | 32 | 40 | 4 | 84 | 58 | 13 | 50 | 84 | 55 |
| 45 SG | 20 | 45 | 42 | 4 | 88 | 60 | 14 | 65 | 100 | 60 |
| 65 SG | 30 | 65 | 70 | 4 | 144 | 84 | 30 | 96 | 140 | – |
| 80 SG | 35 | 90 | 90 | 6 | 186 | 93 | 46.5 | 122 | 175 | – |
| 100 SG | 40 | 100 | 110 | 8 | 228 | 102 | 63 | 150 | 210 | – |
| 125 SG | 50 | 125 | 140 | 10 | 290 | 134 | 78 | 190 | 270 | – |
5. Why choose Dai Hong Phat Corp?
– 100% genuine products imported directly from KTR Germany.
– Protect customers from counterfeit goods and always provide full CO/CQ documents.
– Goods in stock, fast delivery nationwide 24/7.
– Free technical consultation and support for drawings, catalogs.
– Refined processing workshop to meet individual requirements.
—————-/—————–/—————–/—————–/—————–
With more than 15 years of experience, Dai Hong Phat Transmissions Shaft Couplings is proud to be a trusted partner of hundreds of domestic and foreign enterprises.
Let us accompany your sustainable development!
