Let’s learn about KTR Flexible Couplings Evolastic E/EP with Dai Hong Phat, through the following article!
1. About Dai Hong Phat Corp- KTR Germany
– Dai Hong Phat Corp is the official authorized representative of KTR Germany in Vietnam (KTR Vietnam). We provide genuine transmission shaft coupling solutions, meeting international standards, helping to optimize the performance and durability of machinery systems.
– KTR was established in 1959 in Germany. KTR is an abbreviation of
K – Kupplung (Coupling) | T – Technology (Technology) | R – Rheine (Region)
– KTR products: Rotex shaft coupling, Clampex shaft locking joint, hydraulic brake, …
– KTR Flexible Couplings Evolastic E/EP products supplied by Dai Hong Phat are 100% genuine imported, with full CO/CQ, meeting international quality standards.
Certificate of Dai Hong Phat as Authorized Distributor of KTR Germany in Vietnam
See more: Other KTR Flexible Couplings
2. Characteristics of KTR Flexible Couplings Evolastic E/EP
– Manufacturer brand: KTR Germany.
– Torque range: 0 – 5,600 Nm.
– These couplings offer high flexibility for applications in drive systems of IC engines and frequency control.
– With their soft torsional characteristic, they act as insulation against vibrations and noise in the drive system.
– They are available in various stiffness options.
– The couplings compensate for shaft misalignment, radial and angular misalignment, and offer flexible load absorption.
– Type E can be bolted onto the shaft and is available in 11 sizes.
– Type EP can be plugged onto the shaft and is available in 11 sizes.
– They are made from high-quality NR and EPDM elastic materials.
– The couplings are constructed with enclosed elastic elements, vulcanized with natural rubber (WN, SN, MN, up to 90°C) or with synthetic EPDM material (WE, SE, ME, up to 110°C) for higher temperature applications.
See product: KTR Flexible Couplings Evolastic E2H/E2HP
| MỌI THẮC MẮC HOẶC YÊU CẦU BÁO GIÁ, QUÝ KHÁCH VUI LÒNG LIÊN HỆ: PHÒNG KINH DOANH HOTLINE: 0906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN |
3. Applications of KTR Flexible Couplings Evolastic E/EP
The Evolastic E/EP highly flexible couplings from KTR Germany are high-quality products. They are a new type of coupling that has become widely used in factories, especially in drive systems of IC engines and frequency control applications.
One of their special features is that they are made from elastic materials, which helps transmit torque, compensate for shaft misalignment, radial and angular misalignment, and, most importantly, absorb loads flexibly. Additionally, these couplings reduce noise, providing effective manufacturing solutions.
4. Technical specifications of Evolastic E/EP Highly Flexible Coupling
| Catalogue Evolastic E/EP |
Installations Evolastic E/EP |
||||||
 |
|
| Size | Dimensions [mm] | Torque [Nm] |
Weight [kg] | |||||
| DH | DI1 | B1 | B2 | D4 | E | EP | ||
| 12 | 122 | 60 | 32 | 28 | 100 | 71 | 0.5 | 0.55 |
| 24 | 150 | 70 | 42 | 36 | 125 | 123 | 0.93 | 1.03 |
| 32 | 150 | 70 | 42 | 36 | 125 | 123 | 1.13 | 1.26 |
| 48 | 170 | 85 | 46 | 40 | 140 | 195 | 1.55 | 1.74 |
| 60 | 200 | 100 | 58 | 50 | 165 | 302 | 2.28 | 1.52 |
| 86 | 200 | 100 | 58 | 50 | 165 | 302 | 2.76 | 3.08 |
| 125 | 260 | 125 | 70 | 63 | 215 | 592 | 4.74 | 5.16 |
| 200 | 260 | 125 | 70 | 63 | 215 | 592 | 5.79 | 6.35 |
| 280 | 300 | 145 | 80 | 72 | 250 | 592 | 7.89 | 8.71 |
| 360 | 340 | 160 | 85 | 78 | 280 | 592 | 11.5 | 12.21 |
| 560 | 363 | 170 | 105 | 95 | 300 | 1017/592 | 15.38 | 17.67 |
5. Why choose Dai Hong Phat Corp?
– 100% genuine products imported directly from KTR Germany.
– Protect customers from counterfeit goods and always provide full CO/CQ documents.
– Goods in stock, fast delivery nationwide 24/7.
– Free technical consultation and support for drawings, catalogs.
– Refined processing workshop to meet individual requirements.
—————-/—————–/—————–/—————–/—————–
With more than 15 years of experience, Dai Hong Phat Transmissions Shaft Couplings is proud to be a trusted partner of hundreds of domestic and foreign enterprises.
