1. Why choose Dai Hong Phat Corp as the supplier for ETP-EXPRESS Locking Assembly?
– You will be purchasing ETP hub shaft connections directly imported from ETP/Sweden by Dai Hong Phat.
– You can have absolute peace of mind as Dai Hong Phat will protect you against counterfeit products, ensuring the authenticity of the ETP locking assembly.
– Dai Hong Phat corp provides complete CO/CQ documentation for the products.
– Genuine product connections are always available in Dai Hong Phat’s warehouse, ensuring swift delivery to customers without delay.
– The technical drawing of the purchased ETP-EXPRESS hub-shaft connections will be provided upon request by Dai Hong Phat.
– Dai Hong Phat’s dedicated technical team is always available to provide attentive support and advice regarding the ETP hub shaft connections.
– We offer free consultation on optimal solutions for your plant’s needs with genuine ETP locking assembly.
– Dai Hong Phat company provides customers with the official catalogue of products.
– Customers will receive free customization of technical specifications and sizes of ETP hub shaft connections upon request.
– We offer nationwide delivery 24/7, minimizing downtime for customers.
– Our professional machining workshop can provide customized services tailored to your specific needs regarding genuine ETP locking assembly from ETP/Sweden.
2. Dai Hong Phat Corp. is the specialized representative providing all ETP-EXPRESS Hub-Shaft Connections products across Vietnam:
– Dai Hong Phat Corp is the authorized distributor of ETP Sweden in Vietnam.
– With over 15 years of reputation, Đại Hồng Phát ensures customers can purchase genuine ETP-EXPRESS hub-shaft connections with 100% quality and the best prices on the market.
3. Characteristics of The ETP-EXPRESS Hub-Shaft Connections:
– The ETP-Express Hub Shaft Connections are manufactured by ETP/Sweden.
– Operating environment: -30°C to +80°C.
– Extremely fast assembly and disassembly with only 1 screw.
– Radially tightened screw saves space along the shaft.
– Extremely compact size.
– Accurate positioning without axial displacement during installation.
– Excellent concentricity, with deviation ≤ 0.02 mm after multiple installations.
– Torque range from 46Nm to 17000Nm.
– Available in standard shaft sizes from 15mm to 100mm.
View more product “ETP-HYLOC Hub-Shaft Connections“
| FOR ANY INQUIRIES OR QUOTATION REQUESTS, PLEASE CONTACT: SALES DEPARTMENT HOTLINE: +84906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN |
4. Applications of the ETP-EXPRESS Hub-Shaft Connections:
The ETP-Express Hub Shaft Connections are a high-precision hydraulic connection. It is designed compactly for applications requiring quick and accurate shaft adjustments.
The shaft locking screw is tightened radially, meaning there is no axial gap along the shaft for tool insertion. Other components can be mounted on the shaft up to the face of the flange.
The ETP Hub Shaft Connections function similarly to KTR, Ringfeder, and MAV hub shaft connections. They are commonly used in various industrial applications such as gear wheels, levers, rollers, pulleys, sliding gear mechanisms, belt drums, running wheels, and cable pulleys.
5. Technical of The ETP-EXPRESS Locking Assembly:
| Catalogue ETP-Express |
Installation ETP-Express |
||||||
 |
|
| Technical ETP-EXPRESS | |||||||||
| ETP EXPRESS | Dimensions | Transmittable | |||||||
| d | D | D1 | D2 | L | L1 | T | FA | FR | |
| 15 | 15 | 18 | 46 | 48,9 | 25 | 39 | 46 | 5,1 | 0,5 |
| 5/8″ | 15,875 | 19 | 47 | 49,8 | 26 | 40 | 53 | 5,5 | 0,5 |
| 19 | 19 | 23 | 50,5 | 53,0 | 28 | 42 | 85 | 7,3 | 1 |
| 3/4″ | 19,05 | 23 | 50,5 | 53,0 | 28 | 42 | 85 | 7,3 | 1 |
| 20 | 20 | 24 | 51,5 | 54,1 | 30 | 44 | 110 | 9,1 | 1 |
| 22 | 22 | 27 | 55,5 | 60,5 | 32 | 46 | 130 | 9,6 | 1,2 |
| 7/8″ | 22,225 | 27 | 55,5 | 60,5 | 32 | 46 | 130 | 9,6 | 1,2 |
| 24 | 24 | 29 | 57,5 | 62,3 | 33 | 47 | 190 | 13 | 1,4 |
| 25 | 25 | 30 | 58 | 62,9 | 35 | 49 | 230 | 15 | 1,5 |
| 1″ | 25,4 | 31 | 59 | 63,8 | 35 | 49 | 190 | 12 | 1,5 |
| 28 | 28 | 34 | 63 | 69,6 | 38 | 52 | 280 | 16 | 1,8 |
| 1 1/8″ | 28,575 | 35 | 63,5 | 70,1 | 39 | 53 | 290 | 16 | 1,8 |
| 30 | 30 | 36 | 64,5 | 71,0 | 40 | 54 | 380 | 21 | 2 |
| 1 1/4″ | 31,75 | 39 | 68,5 | 77,7 | 42 | 56 | 430 | 22 | 2,2 |
| 32 | 32 | 39 | 68,5 | 77,7 | 42 | 56 | 440 | 22 | 2,2 |
| 1 3/8″ | 34,925 | 42 | 73 | 85,1 | 45 | 59 | 640 | 30 | 2,5 |
| 35 | 35 | 42 | 73 | 85,1 | 45 | 59 | 640 | 30 | 2,5 |
| 1 7/16″ | 36,5125 | 44 | 74,5 | 86,6 | 48 | 62 | 740 | 33 | 2,6 |
| 38 | 38 | 46 | 84,5 | 89,5 | 52 | 72 | 890 | 38 | 2,8 |
| 1 1/2″ | 38,1 | 46 | 84,5 | 89,5 | 52 | 72 | 890 | 38 | 2,8 |
| 40 | 40 | 48 | 86,5 | 91,2 | 55 | 75 | 1100 | 45 | 3 |
| 42 | 42 | 51 | 89 | 93,5 | 56 | 76 | 1100 | 43 | 3,2 |
The benefits of purchasing ETP-EXPRESS hub-shaft connections from Dai Hong Phat Company are as follows:
– Established since 1973 and with years of experience, ETP has made significant advancements in heavy-duty industrial coupling products.
– Dai Hong Phat has partnered with ETP from Sweden, a leading European and global manufacturer of power transmission equipment.
– We at Dai Hong Phat are committed to providing 100% genuine ETP-EXPRESS hub-shaft connections, with new quality, certification, and clear origin of the product.
– Our core value is to bring substantial benefits to customers by offering optimized solutions for hydraulic coupling products in Vietnam. The ETP hub shaft connections distributed by Dai Hong Phat are genuine and authentic.
