ETP-POWER HUB-SHAFT CONNECTIONS

The ETP-POWER Hub-Shaft Connections are a hydraulic connection consisting of a double-sided hardened steel sleeve. The flange part contains screws and a piston with a sealing ring to maintain pressure. There are two pre-machined holes in the flange that can be used to mount positioning pins, screws into the pillar, or similar objects. It can handle torque up to 1600Nm and operates in environments ranging from 0°C to +70°C.

Description

5/5 - (3 votes)

1. Why choose Dai Hong Phat Corp as the supplier for ETP-HYLOC hub shaft connections?

– You will be purchasing ETP locking device directly imported from ETP Sweden by Dai Hong Phat.
– You can have absolute peace of mind as Đại Hồng Phát will protect you against counterfeit products, ensuring the authenticity of the ETP-POWER locking assembly.
– Dai Hong Phat corp provides complete CO/CQ documentation for the ETP-POWER.
– Genuine ETP-POWER hub shaft connections are always available in Đại Hồng Phát’s warehouse, ensuring swift delivery to customers without delay.
– The technical drawing of the purchased ETP-POWER hub shaft connections will be provided upon request by Dai Hong Phat.
– Dai Hong Phat’s dedicated technical team is always available to provide attentive support and advice regarding the ETP hub-shaft connections.
– We offer free consultation on optimal solutions for your plant’s needs with genuine ETP locking assembly.
– Dai Hong Phat provides customers with the official catalogue of ETP hub shaft connections.
– Customers will receive free customization of technical specifications and sizes of ETP-POWER locking assembly upon request.
– We offer nationwide delivery 24/7, minimizing downtime for customers.
– Our professional machining workshop can provide customized services tailored to your specific needs regarding genuine ETP locking assembly from ETP/Sweden.

2. Dai Hong Phat Corp. is the specialized representative providing all ETP-HYLOC Hub-Shaft Connections products across Vietnam:

– Dai Hong Phat Corp is the authorized distributor of ETP Sweden in Vietnam.
– With over 15 years of reputation, Đại Hồng Phát ensures customers can purchase genuine ETP-POWER hub-shaft connections with 100% quality and the best prices on the market.

3. Đặc điểm của khóa đầu trục ETP-TECHNO:

– The ETP-POWER Locking Assembly are manufactured by ETP/Sweden.
– Operating temperature range: 0°C to +70°C.
– High radial load-bearing capacity.
– Quick installation/removal with just one screw.
– Good concentricity, ≤ 0.03 mm after multiple installations.
– Compact integrated size.
– The axial tightening of the screw saves space along the shaft.
– Accurate positioning, no axial displacement during installation.
– Torque range from 60Nm to 1600Nm.
– Available in standard shaft sizes from 15mm to 40mm.

View more product “ETP-TECHNO Hub-Shaft Connections“

MỌI THẮC MẮC HOẶC YÊU CẦU BÁO GIÁ, QUÝ KHÁCH VUI LÒNG LIÊN HỆ:
PHÒNG KINH DOANH
HOTLINE: 0906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN

4. Applications of the ETP-POWER Locking Assembly:

The ETP-POWER Hub-Shaft Connections are a high-performance hydraulic connection among ETP single-threaded central shaft connections. ETP-POWER is designed to be compact, easy to handle, and highly precise, combined with its high radial load-bearing capacity due to the specific characteristics of the pressure environment.
ETP-POWER shaft locking coupling functions similarly to KTR, Ringfeder, and MAV shaft locking couplings. They are widely used in various applications such as wheel hubs, levers, ratchets, pulleys, sliding gear mechanisms, belt drums, running wheels, and cable pulleys in manufacturing plants.

5. Technical of the ETP-POWER Hub-Shaft Connections:

Catalogue ETP-POWER				Installation ETP-POWER

*Technical drawing of The ETP-POWER Hub-Shaft Connections*

Technical ETP-POWER
ETP POWER	Dimensions						Transmittable
ETP POWER	d	D	D1	D2	L	L1	T	F_A	F_R
15	15	20	51	55	21	35	60	7	2
19	19	26	54	58	27	41	100	8	4
3/4”	19.05	26	54	58	27	41	100	8	4
20	20	27	55	59	28	42	130	11	4
22	22	29	58	62	29	43	210	15	4.8
24	24	32	64	70	33	47	230	15	5.6
25	25	33	67	72	34	48	300	20	6
1”	25.4	33	67	72	34	48	300	20	6
28	28	37	70	76	35	49	325	20	7.2
30	30	39	72	80	36	50	530	26	8
1 1/4″	31.75	43	85	92	38	58	550	26	8.8
32	32	43	85	92	38	58	550	26	8.8
35	35	46	88	94	40	60	900	40	10
38	38	50	90	96	44	64	1150	47	11.2
1 1/2″	38.1	50	90	96	44	64	1150	47	11.2
40	40	53	91	96	47	67	1200	47	12
1 3/4″	44.45	58	103	114	51	71	1600	70	14

The benefits of purchasing ETP-POWER hub-shaft connections from Dai Hong Phat Company are as follows:

– Established since 1973 and with years of experience, ETP has made significant advancements in heavy-duty industrial coupling products.
– Dai Hong Phat has partnered with ETP from Sweden, a leading European and global manufacturer of power transmission equipment.
– We at Dai Hong Phat are committed to providing 100% genuine ETP-POWER hub-shaft connections, with new quality, certification, and clear origin of the product.
– Our core value is to bring substantial benefits to customers by offering optimized solutions for hydraulic coupling products in Vietnam. The ETP hub shaft connections distributed by Dai Hong Phat are genuine and authentic.
