1. Why choose Dai Hong Phat as a supplier for Rathi-Lovejoy couplings?
– You will buy 100% genuine couplings imported directly from Rathi-Lovejoy by Dai Hong Phat.
– Customers can rest assured because Dai Hong Phat will protect your risks against counterfeit products of Rathi-Lovejoy.
– Dai Hong Phat we provide full CO/CQ documents.
– N-Flex Couplings type RN/RNS are always available in Dai Hong Phat company’s warehouse so they will be delivered quickly to customers.
– Dai Hong Phat Company will provide you with technical drawings of the Rathi-Lovejoy product you have purchased (upon your request).
– Dai Hong Phat always provides dedicated support and advice to customers about joints because we always have a team of highly professional technical experts available.
– Dai Hong Phat is always ready to provide free consultation on optimal solutions for customers’ factories regarding genuine Rathi-Lovejoy products from the Rathi-Lovejoy brand.
– You will be provided by Dai Hong Phat with a genuine catalog of N-Flex Couplings.
– You will be free of charge by Dai Hong Phat Company to convert the technical specifications and dimensions of Rathi coupling products according to your request.
– A large amount of stock available. Same day dispatch available, giving you peace of mind to minimize downtime while your machinery is operating.
– Dai Hong Phat Customized Solutions For Specific Requirements
2. Dai Hong Phat Corp. is a representative specializing in providing all N-Flex Couplings Type RN/RNS products in Vietnam:
– Dai Hong Phat Company is the importer and distributor of all 100% genuine N-Flex couplings type RN/RNS of the Lovejoy Rathi brand throughout Vietnam.
– Dai Hong Phat Company is committed to more than 15 years of prestige, the company ensures to provide customers with 100% genuine Rathi-Lovejoy coupling products with high quality and the best prices on the market.
3. Charateristics of N-Flex Couplings Type RN/RNS:
– N-Flex Couplings type RN/RNS manufactured by Rathi-Lovejoy/India.
– It’s a type of flexible coupling with a common design of 2 hubs and 1 cushion. The coupling consists of cast iron hubs and a set of high-resilience ‘H’ shaped blocks suitable for parallel, angular, and axial misalignments while absorbing torsional vibrations. N-Flex Coupling is suitable for “Pull-Out” pump applications where the impeller can be removed without affecting the motor and pump from the base frame.
– The damping rubber of the Rathi N-Flex coupling comes in two forms:
+ H-shaped – used for N-Flex type RN(B) and RNS(H) couplings.
+ Cross-shaped – used for N-Flex type RN(A) couplings.
It reduces vibration and noise resulting from severe torque oscillations. The operating temperature ranges from -30°C to +120°C.
View more product “Jaw flex couplings type H/HR“
| FOR ANY INQUIRIES OR QUOTATION REQUESTS, PLEASE CONTACT: SALES DEPARTMENT HOTLINE: (+84) 0906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN |
4. Applications of Rathi-Lovejoy N-Flex Couplings Type RN/RNS:
– N-Flex Couplings type RN/RNS is primarily designed for pump applications, offering:
– Simple and easy maintenance.
– No complex mechanisms requiring adjustment or maintenance. Rubber damping elements of the N-Flex are easily checked and replaced.
– Applications: Water pumps, Slurry pumps, Sewage pumps, Pull-Out pumps, Multistage pumps, Overflow pumps, API pumps, Chemical processing pumps, Metering/dosing pumps, Gear pumps, Paper pumps, Screw pumps, Vacuum pumps, Fire pumps, High-pressure pumps.
5. Technical of Rathi-Lovejoy N-Flex RN Couplings:
| Catalogue N-Flex Couplings |
Installations N-Flex Couplings |
 |
|
| Coupling Size | Max. Speed RPM | MAX. BORE (mm) |
DIMENSIONS (mm) |
WEIGHT (kg.) | |||||||||
| D1 | D2 | D3 | ØA | ØB1 | L1 | L2 | T1 | T2 | RN(B) | RN(A) | RNS(H) | ||
| 68 B | 7000 | 24 | 24 | – | 68 | 68 | 20 | – | 21 | 8 | 0.54 | – | – |
| 80 B,H | 6000 | 30* | 38 | – | 80 | 80 | 30 | 45 | 31 | 10 | 1.3 | – | 2.6 2.7 |
| 95 B,H | 5500 | 42 | 42 | – | 95 | 76 | 35 | 45 | 30 | 12 | 2.2 | – | 3.5 3.8 |
| 110 A,B,H | 5300 | 48 | 48 | 38 | 110 | 86 | 40 | 50 | 34 | 14 | 3.3 | 3 | 5.2 5.4 6.0 |
| 125 A,B,H | 5100 | 55 | 55 | 45 | 125 | 100 | 50 | 50 | 36 | 18 | 5.2 | 4.8 | 7.2 7.7 8.2 |
| 140 A,B,H | 4900 | 60 | 60 | 50 | 140 | 100 | 55 | 55 | 34 | 20 | 5.6 | 6 | 10.0 10.5 11.0 |
| 160 A,B,H | 4250 | 65 | 65 | 58 | 160 | 108 | 60 | 60 | 39 | 20 | 7.8 | 8.4 | 13.0 13.7 14.5 |
| 180 A,B,H | 3800 | 75 | 75 | 65 | 180 | 125 | 70 | 70 | 42 | 20 | 11.5 | 12 | 18.5 19.4 |
| 200 A,B,H | 3400 | 85 | 85 | 75 | 200 | 140 | 80 | 80 | 47 | 24 | 16 | 17 | 25.6 36.5 27.2 28.5 |
| 225 A,B,H | 3000 | 90 | 90 | 85 | 225 | 150 | 90 | 90 | 52 | 18 | 20 | 23 | 34.0 35.0 36.0 38.0 |
| 250 A,B,H | 2750 | 100 | 100 | 95 | 250 | 165 | 100 | 100 | 60 | 18 | 29 | 31 | 48.0 50.0 52.0 |
Customers who purchase N-Flex RN Couplings from Dai Hong Phat are entitled to the following benefits:
– Dai Hong Phat collaborates with Rathi-Lovejoy, a brand from India specializing in providing genuine overload protection equipment with superior performance.
– We guarantee that N-Flex Couplings Type RN/RNS are 100% genuine, brand new, certified, and clearly sourced.
– The core value of our cooperation is to bring significant benefits to customers regarding shaft coupling solutions. Rathi-Lovejoy Flexible Couplings distributed by Dai Hong Phat are genuine products.
