Let’s learn about Wichmann Cardan Shaft Couplings Type 100 with Dai Hong Phat through the following article!
1. About Dai Hong Phat – Wichmann Germany
– Dai Hong Phat is an authorized representative and official distributor of Wichmann Germany in Vietnam. We provide genuine transmission shaft coupling solutions that meet international standards, helping to optimize the performance and durability of machinery systems.
– Wichmann has been operating for more than 40 years in the field of transmission solutions: manufacturing cardan shaft couplings. Providing outstanding operational reliability, long life and low operating costs. Applied in the industrial and automotive industries.
– The Wichmann Type 100 Cardan Shaft Coupling product supplied by Dai Hong Phat is 100% genuine imported, with full CO/CQ, meeting international quality standards.
2. Applications of the Wichmann Cardan Shaft Couplings Type 100:
– The Wichmann cardan shafts type 100 are manufactured by Wichmann/Germany.
– Flanges designed according to DIN, SAE, cross serration, DIN with spline on face, Hirth-serration
– Capable of operating in harsh conditions
– High load-bearing capacity
– Allows angular misalignment up to 25 degrees and maximum torque of 3,900,000 Nm.
View more product “Wichmann cardan shafts type 130“
| FOR ANY INQUIRIES OR QUOTATION REQUESTS, PLEASE CONTACT: SALES DEPARTMENT HOTLINE: +84 906 955 057 – EMAIL: INFO@DHP-CORP.COM.VN |
3. Applications of the Wichmann Cardan Shaft Type 100:
The Wichmann Cardan Shafts Type 100 is a versatile component widely used across various industries. Its applications span from automotive drivetrains to industrial machinery, marine propulsion systems, construction equipment, mining operations, agricultural machinery, and material handling systems. With its ability to transmit torque efficiently while accommodating misalignments and vibrations, the Cardan Wichmann plays a crucial role in ensuring smooth and reliable power transmission in diverse operational environments.
4. Technial drawing of the Wichmann Cardan Shafts Type 100:
| Catalogue Cardan Wichmann Type 100 |
Installation Cardan Wichmann Type 100 |
||||||
 |
|
|
Type 100 |
Torque [Nm] |
Dimensions [mm] |
Flange [mm] |
||||
|
L1 Min |
L2 Min |
Tube size |
DIN |
SAE |
Cross serraon |
||
|
7600 |
600 |
250 |
40 |
50 |
75-6-6 90-4-8 |
87-4-8 |
|
|
10000 |
1400 |
421 |
110 |
50/76.2 |
90-4-8 100-6-8 100-8-8 120-8-8 120-8-10 |
87-4-8 96,8-4-9,6 |
100-4-8,5 122-4-11 |
|
11600 |
3000 |
451 |
110 |
70/90 |
100-6-8 100-8-8 120-8-8 120-8-10 150-8-12 |
119-4-11,1 149-4-12,7 |
122-4-11 |
|
12600 |
5300 |
536 |
110 |
90 |
120-8-10 150-8-12 180-8-10 180-8-14 |
146-4-12,7 |
122-4-11 |
|
14400 |
6000 |
572 |
110 |
100 |
150-8-12 180-8-14 |
174,8-8-9,6 |
122-4-11 150-4-13 |
|
15800 |
8800 |
630 |
180 |
100 |
150-8-12 180-8-14 180-8-16 180-10-16 |
174,8-8-9,6 203,2-8-9,6 203,2-12-11,1
|
150-4-13 180-4-15 |
5. Why choose Dai Hong Phat?
– 100% genuine products imported directly from Wichmann Germany.
– Protect customers from counterfeit goods and always provide full CO/CQ documents.
– Goods in stock, fast delivery nationwide 24/7.
– Free technical advice and support for drawings and catalogs.
– Fine-tuning workshop to meet individual requirements.
—————–/—————–/—————–/—————–/—————–
With more than 15 years of experience, Dai Hong Phat Shaft Coupling is proud to be a trusted partner of hundreds of domestic and foreign enterprises.
Let us accompany your sustainable development!
